Engine Complete Assembly - 866T, Engine, Base - 866T, Front Sump with SAE #3 Flywheel Housing
Engine Complete Assembly - 866T Engine, Base - 866T, Front Sump with SAE #3 Flywheel Housing
13048
Custom built 275-575 hp / 600-900 lb-ft
Every build is custom. Max RPM 4400 with 90 Degree V8 6.6L (403ci). Engine management with Banks AutoMind Electronic Diesel Controller.
Prices start from $30,895
Call to custom build yours today
Every build is custom. Max RPM 4400 with 90 Degree V8 6.6L (403ci). Engine management with Banks AutoMind Electronic Diesel Controller.
Prices start from $30,895
Call to custom build yours today
Please Call for Availability
800-601-8072
Shipping: All Gale Banks engines are custom built and shipping arrangements will be determined at time of order. Call for pricing (800) 601-8072
Description
The Banks Powertrain 866T is a high-performance V8 turbo diesel engine displacing 6.6L and is available with ratings up to 575 hp. It features an internally gear driven camshaft, water pump, aluminum cylinder heads and a high-strength iron block. It is common rail equipped and controlled by the AutoMind EDC featuring J1939 CAN communications, gear-based torque management, OBD-II style diagnostics, and many active protection features. A variable speed governor is available for applications requiring active engine speed management.
- Engine Complete Assembly
- Prices start from $39,895
- Every build is custom
- 275-575 hp / 600-900 lb-ft
- Max RPM 4400
- Configuration 90 Degree V8
- 6.6L (403ci)
- Engine management with Banks AutoMind Electronic Diesel Controller
- Call to custom build yours today
Features:
- Rated Power: 425 horsepower
- Peak Torque: 725 lb-ft
- Rated Speed: 3,200 RPM
- Fuel Type: Diesel
- Complete FEAD with Alternator and Power Steering Pump
- Front oil sump
- GM standard flywheel housing
- Complete Bosch fuel injection system
- 12V glow plug system
- Automind® Electronic Diesel Controller and associated wiring harness
- All NEW components used in build
- Hot-tested to ensure quality
- Component Dry Weights:
Engine: 912 lbs w/o accessories
Transmission: 211 lbs w/ 300mm converter
Total Powertrain Weight: 1123 lbs - NO CORE CHARGE
- 90 day material and workmanship warranty
Optional Upgrades:
- Power Rating: 275-575HP / 3000-3800 RPM
- Banks Severe Duty Crankshaft Vibration Dampener and Accessory Drive w/ Dual 200A alternators
- Banks SpeedBrake Integrated exhaust brake
- Banks Multi-plate Lockup Torque Converter
- Techni-Cooler intercooler
- Banks Severe Duty intake Manifold
- CAN-networked Transmission Controller
- Banks 6745E 6-Speed automatic transmission
First Gear: 4.03
Sixth Gear: 0.67:1 Overall Gear Spread: 6.01
VIDEO BONUS! In case you didn't see it above, watch Adam Carolla check out the Banks 866T!
Videos
Details
- 13048
- 13048
- 801279130487
- Banks Power
- New
Categories
Shipping Information
- Item Requires Shipping
- 912.0 lbs.
- W30.0000” x H34.0000” x L31.0000”
- This item ships in its own box.
- All Gale Banks engines are custom built and shipping arrangements will be determined at time of order. Call for pricing (800) 601-8072
